TP Fire S fire-rated glass partitions - wall types
Unclassified. For example, 10 mm toughened glass jointed using an 80 mm joint.
Find all information about TP Fire on our download page
![TP Fire S 10 mm, uklass. TP Fire S 10 mm, uklass.](typo3temp/_processed_/csm_314.10.1001_uklass_vaegtyper_uk_191ad4146c.png)
Fire classification E30. 8 mm PY8-E30 fire-rated glass jointed with 80 mm metal joint.
Find all information about TP Fire on our download page
![TP Fire S 8 mm, E30 TP Fire S 8 mm, E30](typo3temp/_processed_/csm_314.10.1001_8mm_vaegtyper_uk_192417df7c.png)
Fire classification EW30. 13 mm CFL-EW30 fire-rated glass jointed with 80 mm metal joint.
Find all information about TP Fire on our download page
Fire classification EW30 also complies with the requirements of classification E60.
![TP Fire S 13 mm, EW30 TP Fire S 13 mm, EW30](typo3temp/_processed_/csm_314.10.1001_13mm_vaegtyper_uk_25ea4be6a6.png)
Fire classification EW30. 13 mm CFL-EW30 fire-rated glass jointed with 80 mm metal joint.
Find all information about TP Fire on our download page
Fire classification EW30 also complies with the requirements of classification E60.
![TP Fire S 13 mm, E60 TP Fire S 13 mm, E60](typo3temp/_processed_/csm_314.10.1001_13mm_vaegtyper_uk_01_81ef69c3fb.png)
Fire classification EW60. 14 mm CFL-EW60 fire-rated glass jointed with 80 mm metal joint.
Find all information about TP Fire on our download page
![TP Fire S 14 mm, EW60 TP Fire S 14 mm, EW60](typo3temp/_processed_/csm_314.10.1001_14mm_vaegtyper_uk_da8f53e21e.png)
Fire classification EI30. 16 mm CF-EI30 fire-rated glass jointed with 95 mm metal joint.
Find all information about TP Fire on our download page
![TP Fire S 16 mm, EI30 TP Fire S 16 mm, EI30](typo3temp/_processed_/csm_312.10.1001_16mm_vaegtyper_uk_c290baff53.png)
Fire classification EI60. 25 mm CF-EI60 fire-rated glass jointed with 95 mm metal joint.
Find all information about TP Fire on our download page
![TP Fire S 25 mm, EI60 TP Fire S 25 mm, EI60](typo3temp/_processed_/csm_310.10.1001_25mm_vaegtyper_uk_06cd24b42a.png)
|
|
|
|
|
| |
---|---|---|---|---|---|---|
TP Fire S 10 mm | 10 | 50 | - | - | Unclass. | |
TP Fire S 8 mm | 8 | 50 | 20 | 34 | E30 | |
TP Fire S 13 mm | 13 | 50 | 30 | 38 | EW30 | |
TP Fire S 13 mm | 13 | 50 | 30 | 38 | E60 | |
TP Fire S 14 mm | 14 | 50 | 31 | 38 | EW60 | |
TP Fire S 16 mm | 16 | 60 | 34 | 38 | EI30 | |
TP Fire S 25 mm | 25 | 70 | 52 | 41 | EI60 |
