Wall types Ventura/Open system wall
100 mm single wall consisting of a 72 mm steel structure with a 13 mm plasterboard on each side. Insulated with 50 or 75 mm mineral wool. Find all information about Ventura/Open on our download page

125 mm single wall consisting of a 72 mm steel structure with two 13 mm plasterboards on each side. Insulated with 50 mm mineral wool. Find all information about Ventura/Open on our download page

100 mm single wall consisting of a 49 mm steel structure with two 13 mm plasterboards on one side and 13+9 mm on the other side. Insulated with 50 mm mineral wool. Find all information about Ventura/Open on our download page

165 mm double wall consisting of 2x49 mm steel structure with two 13 mm plasterboards on each side. Insulated with 2x50 mm mineral wool. Find all information about Ventura/Open on our download page

100 mm single wall consisting of a 72 mm steel structure with a 13 mm plasterboard on each side.
Insulated with 50 or 75 mm mineral wool. Find all information about Ventura/Open on our download page

125 mm single wall consisting of a 72 mm steel structure with two 13 mm plasterboards on each side. Insulated with 50 mm mineral wool. Find all information about Ventura/Open on our download page

100 mm single wall consisting of a 49 mm steel structure with two 13 mm plasterboards on one side and 13+9 mm on the other side. Insulated with 50 mm mineral wool. Find all information about Ventura/Open on our download page

165 mm double wall consisting of 49 mm steel structure with two 13 mm plasterboards on each side.
Insulated with 2x50 mm mineral wool. Find all information about Ventura/Open on our download page

|
|
|
|
|
|
| |
---|---|---|---|---|---|---|---|
Ventura 1-11 (TV1-11) | 100 | 50/75 | 28 | 44 | BS30 | 72 | |
Ventura 1-12 (TV1-12) | 125 | 50 | 47 | 48 | BS60 | 72 | |
Ventura 2-12 (TV2-12) | 100 | 50 | 46 | 48 | BS60 | 49 | |
Ventura 2-22 (TV2-22) | 165 | 2x50 | 54 | 53 | BS90 | 2x49 | |
Ventura Open (TVO 1-11) | 100 | 50/75 | 28 | 43 | BS30 | 72 | |
Ventura Open (TVO 1-12) | 125 | 50 | 47 | 47 | BS60 | 72 | |
Ventura Open (TVO 2-12) | 100 | 50 | 46 | 47 | BS60 | 49 | |
Ventura Open (TVO 2-22) | 165 | 2x50 | 48 | 52 | BS90 | 2x49 |
