Glazed wall system TRIPLAN LITE | 34 - 43 dB.

Rw 34 - 43 dB

A classic glazed wall solution without high demands to sound-rating. TRIPLAN LITE® |  34 - 43 dB is a classic glazed partition with a single layer of glass. The glass is held in position by runners at head and floor and the glasses are joined vertically using tape. Transoms can be installed afterwards. Glass thickness depends on sound reduction and wall height.



GLASS
Type            Thickness            Sound reduction          Max. height        Fire classification
Toughened glass10 mm34 dB2.4 - 2.7 m-
Toughened glass12 mm35 dB2.9 - 3.4 m-
Toughened glass15 mm37 dB3.4 - 3.9 m-
Toughened + laminated glass12.76 mm 38 dB2.4 - 2.7 m-
Toughened + laminated glass16.76 mm 39 dB3.3 - 3.7 m-
Laminated sound-rated glass12.76 mm40 dB2.2 - 2.5 m-
Laminated sound-rated glass16.76 mm42 dB3.1 - 3.4 m-
Toughened + laminated sound-rated glass12.76 mm40 dB2.4 - 2.7 m-
Toughened + laminated sound-rated glass17.52 mm42 dB3.3 - 3.7 m-
Toughened + laminated sound-rated glass21.52 mm 43 dB4.0 - 4.6 m-
•   The sound reduction depends on which glass type and thickness of glass that is used.
•   The glass thickness depends on the room height.
•   The glass height is a recommendation. Width and height relations are interdependent.

Safety glass

Remember to use the right type of safety glass and that safety glass must be marked to minimise the possibility that inattentive people bump into the glass.






DESIGN CATEGORIES

There are endless design options within the TRIPLAN LITE® glass wall system. We have chosen to divide our designs into three main categories:



ALU: The classic office glazed wall

NEW YORK: The modern take on an old cassic

WOOD: The well-known solutions in a warm and beautiful finish



You are always welcome to contact us, if you have other wishes and ideas.





Glazed wall. Runners in i aluminium
Glazed wall. New York style
Glazed walls. Wooden framing design

Please choose design category:

Design Aluminium
Glazed walls. New York style
Wooden design. Glazed walls.





TRIPLAN LITE®  |  34 - 43 dB - solutions:

You can find projects with classic simple glass wall solutions here:



Carlsberg new headquarter CCO

Hotel Alsik

Aarsleff domicile

CASA A/S new domicile in Horsens

Eusiness Academy in Aarhus

Danish Centre of Particle Therapy
